Sunward SWE 90UF
The Sunward SWE 90UF compact excavator was launched at the end of 2020. The SWE 90UF has been developed especially for Australian conditions, where contractors, from demolition to the rental market, will appreciate a compact machine that delivers heavy-duty performance. It features a very short-tail swing, making it the shortest 9-ton short-tail excavator (by almost 20 cm) available in the market. Thanks to its design, the SWE 90UF can offer great power at a reduced footprint, allowing it to fit into smaller spaces than similar products.
It combines the power of the Yanmar 4TNV98C engine, delivering 46.2 kW, with incredible precision thanks to the dual proportional joysticks, the perfectly fitted hydraulic flow coupled with the LUDFF system (Load Independent Flow Control). To balance fuel consumption and the desired productivity, the SWE 90UF offers 3 working modes.
Of course, because we know that safety and comfort should go hand in hand, the SWE 90UF keeps you safe and provides comfort in all working conditions.
In Sunward’s tradition of always offering the best value for money, the SWE 90UF is no exception. It offers many features and up to 5 years of warranty as standard at the right price.
Emission rating: EU Stage V
Operating weight: 8,750 – 8,900 kg
Power output: 46.2 kW
Max. digging depth: 4,545 mm
Width: 2,250 mm
Specifications:
Discover all the other advantages of the Sunward SWE 90UF.Dimensions:
Operating weight: 8,750– 8,900 kg Standard bucket capacity: 0,26 m³ Shipping length: 6,494 mm Shipping width: 2,250 mm Height over cabin: 2,735 mmEngine:
Model: Yanmar 4TNV98C Emission rating: EU Stage V Displacement: 3.319 L Rated power output: 46.2 kWHydraulic System:
Type: 1 variable piston pump Displacement: 160 L/min Hydraulic pressure: 28 MpaWorking Range
Max. digging depth: 4,545 mm Max. digging reach: 7,445 mm Max. bucket digging force: 63.5 kN Max. arm digging force: 38 kN
Industry-Leading Warranty
5-year/5,000-hour warranty
Benefit from our confidence in product quality with a 5-year/5,000-hour warranty on all machines.
Features & Benefits
POWERFUL & RELIABLE ENGINE
Premium Components
Compact Design
HIGH WORKING RANGE
READY FOR A VARIETY OF APPLICATIONS
WELL-EQUIPPED FROM THE OUTSET
EASY TO MAINTAIN
BEST VALUE FOR MONEY
