SG1000HD

Available
The Toprock SG1000HD Side Grip Pile Driver has been designed to deliver maximum power and precision in heavy-duty foundation and piling operations, where the highest level of specialised gripping capability is essential for handling and driving large-diameter tubular steel piles in demanding applications, including major infrastructure projects, port developments, and offshore renewable energy installations. Engineered with Korean precision and featuring Toprock’s patented side grip technology, the SG1000HD offers unmatched clamping force and 35-degree tilting functionality for quick, accurate positioning of large tubular piles. The specialised grip design accommodates tubular steel piles up to 610mm diameter, while the hydraulic-operated 360-degree rotation enables exact pile placement even in restricted access conditions. Its case drain-ready construction protects your excavator’s hydraulic system, while easily accessible maintenance points ensure minimal downtime even under intensive operation.
Request a Quote
Call 1300 971 884
Download a Brochure
Max. Frequency:
2,700 rpm
Rotation / Tilt angle:
360° / 35 degrees
Operating weight:
2,850 kg
Suitable excavator:
33-45 tonne

Industry-Leading Warranty

3 year/3,000 hour warranty

Benefit from our confidence in product quality with a 3-year/3,000-hour warranty on all machines.

Request a Quote

Features & Benefits

PRECISION ROTATION MOTOR

The hydraulic rotation motor enables exact pile positioning through smooth 360-degree rotation, eliminating the need to reposition your excavator and dramatically reducing cycle times on complex projects while ensuring accurate pile alignment every time.

Precision solenoid valve provides instant control of oil flow and pressure throughout the system, ensuring responsive operation and consistent performance while protecting hydraulic components from pressure spikes and system damage.

A robust rotational gearbox delivers reliable 360-degree rotation, powered by a hydraulic motor, providing smooth and consistent pile positioning even under maximum load conditions while maintaining long-term durability in demanding applications.

High-quality cushion rubbers strategically absorb vibrations before they transfer to your excavator, preventing machine damage, reducing operator fatigue, and extending the service life of your host equipment’s critical components.

Purpose-built gearbox generates powerful vibrations through its built-in eccentric weight system, delivering the centrifugal force needed to drive piles efficiently into challenging soil conditions while maintaining consistent frequency output.

Toprock’s unique, patented side-grip design provides specialised gripping capability for tubular steel piles, offering superior control and positioning compared to conventional jaw systems, while accommodating large-diameter pipes up to 610mm.v

The heavy-duty clamping jaw secures sheet piles and beams with up to 44 tonnes of hydraulic clamping force, ensuring a positive grip throughout the driving cycle and preventing pile slippage, even in the most demanding applications.

The hydraulically operated tilting unit provides 35 degrees of angle adjustment for easy pile positioning and clamping, eliminating the need for repositioning the excavator and reducing the requirement for extra manpower, thereby accelerating project timelines.

Primary hydraulic motor operates the vibro hammer using your excavator’s existing hydraulic system with optimised pressure and flow requirements, delivering maximum vibration power without requiring additional power units or modifications to your machine.
