The Sunward SWE 18UF is a 4-pole canopy mini excavator built for small corners and tight working conditions. Its zero-tail chassis and expandable undercarriage (from 900 mm to 1 320 mm) allow it to reach the smallest spaces, allowing for precise movement even when the space is restricted. In case you need extra support, you can simply widen the undercarriage.
With probably the longest arm in its class, allowing long-reach digging capacity, the SWE 18UF’s boom cylinder design provides a reach over 4 meters (4120 mm) long.
With 3 separate auxiliary lines as standard (the market provides 1 to 2 lines), the SWE 18UF is ready for all types of attachments and can adapt to any job site.
Thanks to a 4-pole canopy design, the high-back adjustable suspension seat, and an ergonomically designed operator workspace, comfort and safety are not at rest.
- Emission rating: EU Stage V
- Operating weight: 1 880 kg
- Power output: 13.4 kW
- Max. digging depth: 2 206 mm
- Width: 990-1 360 mm
Specifications
Discover all the other advantages of the Sunward SWE 18UF.
Dimensions
Operating weight: 1 880 kg
Standard bucket capacity: 0,04 m³
Shipping length: 3 582 mm
Shipping width : 990 mm
Height over canopy: 2 555 mm
Engine
Model: Yanmar 3TNV80F-SSU
Emission rating: EU Stage V
Displacement 1.267 L
Rated power output 13.4 kW
Hydraulic System
Type: 2 Variable Piston Pumps + 1 Gear Pump
Displacement: 50.6 L/min
Hydraulic pressure: 24.5 Mpa
Working Range
Max. digging depth: 2 210 mm
Max. digging reach: 1 675 mm
Max. bucket digging force: 22,7 kN
Max. arm digging force: 11 kN
